Medical Oxygen Gas High Pressure Oxygen Tanks Non Reactive DOT Standard

China Medical Oxygen Gas High Pressure Oxygen Tanks Non Reactive DOT Standard supplier
Medical Oxygen Gas High Pressure Oxygen Tanks Non Reactive DOT Standard supplier Medical Oxygen Gas High Pressure Oxygen Tanks Non Reactive DOT Standard supplier

Large Image :  Medical Oxygen Gas High Pressure Oxygen Tanks Non Reactive DOT Standard

Product Details:

Place of Origin: China
Brand Name: Newradar
Certification: ISO/DOT/GB
Model Number: N/A

Payment & Shipping Terms:

Minimum Order Quantity: 50pcs
Price: negotiation
Packaging Details: Packed in10L-50L cylinder or packed according to the demands.
Delivery Time: 30-35 working days after received your payment
Payment Terms: L/C, , T/T, Western Union, MoneyGram
Supply Ability: 30000 pcs per month
Contact Now
Detailed Product Description
Product Name: Oxygen Gas Purity: 99.9999%
CAS No.: 7782-44-7 EINECS No.: 231-956-9
Molecular Weight: 32 PubChem No.: 24845041
Melting Point: −218.79 °C Boiling Point: −182.962 °C
Grade: Electron Grade And Industrial Solubility: Difficult To Dissolve In Water

Medical Oxygen Gas High Pressure Oxygen Tanks Non Reactive DOT Standard





Description:



Oxygen storage methods include high pressure oxygen tanks, cryogenics and chemical compounds. For reasons of economy, oxygen is often transported in bulk as a liquid in specially insulated tankers, since one liter of liquefied oxygen is equivalent to 840 liters of gaseous oxygen at atmospheric pressure and 20 °C. Such tankers are used to refill bulk liquid oxygen storage containers, which stand outside hospitals and other institutions that need large volumes of pure oxygen gas.



Liquid oxygen is passed through heat exchangers, which convert the cryogenic liquid into gas before it enters the building. Oxygen is also stored and shipped in smaller cylinders containing the compressed gas; a form that is useful in certain portable medical applications and oxy-fuel welding and cutting.

The NFPA 704 standard rates compressed oxygen gas as nonhazardous to health, nonflammable and nonreactive, but an oxidizer. Refrigerated liquid oxygen is given a health hazard rating of 3, and all other ratings are the same as the compressed gas form.



Variations of oxygen shaped the climates of the past. When oxygen declined, atmospheric density dropped and this in turn increased surface evaporation, and led to precipitation increases and warmer temperatures.

At the current rate of photosynthesis it would take about 2,000 years to regenerate the entire O2 in the present atmosphere.



One hundred million tonnes of O2 are extracted from air for industrial uses annually by two primary methods. The most common method is fractional distillation of liquefied air, with N2 distilling as a vapor while O2 is left as a liquid.



Specifications:



1. Physical properties



Commodity High purity oxygen gas
Molecular Formula O2
UN No. UN1072
CAS No.

7782-44-7

Hazardous class for transort 2.2



2. Typical technical data (COA)



Name Purity
O2 99.9999%
N2 < 0.55ppm
Ar < 0.3ppm
THC < 0.7ppm
CO2 < 0.2ppm
CO < 0.1ppm
H2O < 0.5ppm
H2 < 0.1ppm
Kr < 0.1ppm
Xe < 0.1ppm



3. Package



Cylinder Size

Cylinder Content

(m3)

Gauge Pressure

(bar)

Outlet Connection

8ltr 1 100bar According to the valve type
40ltr 5.5 135bar According to the valve type
44ltr 6 150bar CGA580
47ltr 7 165bar CGA580
Other sizes and other standards are also available





Applications:



Life support and recreational use An application of O2 as a low-pressure breathing gas is in modern space suits, which surround their occupant's body with pressurized air. These devices use nearly pure oxygen at about one third normal pressure, resulting in a normal blood partial
pressure of O2.
Industrial Smelting of iron ore into steel consumes 55% of commercially produced oxygen. In this process, O2 is injected through a high-pressure lance into molten iron, which removes sulfur impurities and excess carbon as the respective oxides, SO2 and CO2.
Chemical Ethylene is reacted with O2 to create ethylene oxide, which, in turn, is converted into ethylene glycol; the primary feeder material used to manufacture a host of products, including antifreeze and polyesterpolymers.
Other Oxygen is used in medical applications, metal cutting and welding, as an
oxidizer in rocket fuel, and in water treatment.
