products

Industrial And Medical Premixed Gases In 20L Standard Cylinder Valve Din 8

Basic Information
Place of Origin: China
Brand Name: Newradar Gas
Certification: ISO
Model Number: SY-EXCEIMER
Minimum Order Quantity: 1 pcs
Packaging Details: 8-10L cylinder
Delivery Time: 15-35 days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 1000 Piece/Pieces per Month
Detail Information
CAS No.:: Depend On Compenonet Other Names:: Argon Fluoride Mixtures
Purity:: 99.9%-99.999% Appearance:: Colorless
Application:: Industrial Name: Industrial Gases
High Light:

laser gas mixtures

,

msds natural gas


Product Description



Output wavelength is a function of the rare gas / halogen combination. Excimer is the name of the rare gas / halide molecule. There are four wavelengths (spectral lines) that can be generated from fluorine laser gas mixtures.



PRODUCT NAME: Less than 1% FLUORINE IN ARGON, HELIUM, KRYPTON, NEON and/or XENON

PRODUCT USE: In Excimer Lasers

COMPOSITION and INFORMATION ON INGREDIENTS



Brand Wavelength Cylinder Valve
COHERENT 193nm 20 L DIN 8
Bausch+Lomb(B & L) 193nm 20 L/50 L DIN 8/ DIN 14
ZEISS 193nm 10L/20 L DIN 8
VISX 193nm 16 L CGA 679
NIDEK 193nm 16 L CGA 679
LASERSIGHT 193nm 10 L CGA 679
Alcon 193nm 16 L CGA 679
SCHWIND 193nm 20 L DIN 8/ DIN 14
SUMMIT 193nm 16 L CGA 679







High power excimer laser gas
Available wavelength 193 nm ArF
248 nm KrF
308 nm XeCl
450nm~520nm XeF
Maximum ultraviolet power 540 W
Maximum ultraviolet energy 1100 mj
repeat frequency variable, 1~600 Hz
Pulse stability 0.5%~1%,rms
Long-term drift 0.1%~0.5%,rms
Beam distribution Uniform, flat top
Pulse Width 10~20 ns
Correlation gas purity F2, 99.9%
Ar, 99.9999%
He, 99.9999%
Ne, 99.9999%
HCl, Electronic grade
Kr, 99.999%
Xe, 99.999%
O2, 99.999%
H2, 99.999%
Gas working temperature - 40 0C ~ + 74 0C
gas pressure 520 psig ~ 2400 psig / 35 Bar ~ 167 Bar
Cylinder specifications 10L,16L,20L,50L
Valve interface CGA 679,CGA 330,CGA 580,DIN 6,DIN 8,DIN 14
