Liquid Anhydrous Ammonia NH3 Storage Tanks 400L , 800L Cylinders

Basic Information
Place of Origin: China
Brand Name: Newradar Gas
Certification: GB/ISO/DOT/DOT-ISO/JB/EU
Model Number: N/A
Minimum Order Quantity: 1~10pcs
Price: negotiation
Packaging Details: Packed in carton firstly,and then reinforced with wooden case for outer packing
Delivery Time: 15 working days after received your payment
Payment Terms: T/T, L/C, Western Union, MoneyGram
Supply Ability: 500,000pcs per month
Detail Information
Norminal Working Pressure: 3Mpa Nominal Diameter: 600mm
Capacity: 400L Product Name: Welded Steel Cylinders
Hydraulic Test Pressure: 4.5Mpa Pneumatic Test Pressure: 3Mpa
High Light:

welding gas equipment


welding gas tank

Product Description

Liquid Anhydrous Ammonia NH3 Storage Tanks 400L , 800L Cylinders

Ammonia MSDS.output.pdf





A gas cylinder or tank is a pressure vessel used to store gases at above atmospheric pressure.


During the manufacturing process, vital information is usually stamped or permanently marked on the cylinder. This information usually includes the type of cylinder, the working or service pressure, the serial number, date of manufacture, the manufacture's registered code and sometimes the test pressure. Other information may also be stamped depending on the regulation requirements.

When gases are supplied in gas cylinders, the cylinders have a stop angle valve at the end on top. Often, gas cylinders are somewhat long and narrow and may stand upright on a flattened bottom at one end with the valve at the top. During storage, transportation, and handling when the gas is not in use, a cap may be screwed over the protruding valve to protect it from damage or breaking off in case the cylinder were to fall over. Instead of a cap, cylinders commonly have a protective collar or neck ring around the service valve assembly.


Because the contents are under pressure and are sometimes hazardous materials, there are special safety regulations for handling bottled gases. These include chaining bottles to prevent falling and damaging the valve, proper ventilation to prevent injury or death in case of leaks and signage to indicate the potential hazards. Installing and replacing gas cylinders should be done by competent personnel. If a compressed gas cylinder tips over, causing the valve block to be sheared off, the rapid release of high-pressure gas may cause the cylinder to be violently accelerated, potentially causing property damage, injury, or death. To prevent this, cylinders are normally secured to a fixed object or transport cart with a strap or chain.





Chemical composition of the primary material

Welding material
C Si Mn S P Diameter of welding wire (mm)
0.15 0.25 1.36 0.0004 0.013 4/5


Heat treatment method Heating temperature Duration of heat treatment Cooling
Relieving stress entirely 620℃±20℃ 2 hours Air-cooling
Radiographic inspection
Inspection Standard Inspection percentage Grade of pualification Result
JB/T4730-2005 ≥20 Grade II Qualified





1. They are widely used in industrial&civilian fields as below:

-----Medical care and rescue;

-----Beverage industry;

-----Industrial gases of high purity;

-----Firefighting,medical and mining fields;


Competitive advantage:


1. The thread type,fittings&valves,stamp marks and cylinder’s color could be customized by customer’s



2. Our aluminum alloy gas cylinder can be produced as per Chinese standard and international

standard,such as DOT/EN/ISO and the third-part inspection etc.


Liquid Anhydrous Ammonia NH3 Storage Tanks 400L , 800L Cylinders 0
