Ultra High Purity 99.9999% SiH4 Silane Electronic Gases / Electric Gas Colorless

Basic Information
Place of Origin: China
Brand Name: Newradar
Certification: ISO/DOT/GB
Model Number: N/A
Minimum Order Quantity: 1 pcs
Price: negotiation
Packaging Details: Packed in 40L-50L, 440L cylinder or packed according to the demands.
Delivery Time: 15-25 working days after received your payment
Payment Terms: L/C, , T/T, Western Union, MoneyGram
Supply Ability: 2000 pcs per month
Detail Information
Product Name: Silane Purity: 99.9999%
CAS No.: 7803-62-5 EINECS No.:: 232-263-4
Appearance: Colorless Gas Odor: Repulsive
Melting Point: -185°C Boiling Point: -112°C
High Light:

electric gas

,

purity plus specialty gases


Product Description

Ultra High Purity 99.9999% SiH4 Silane Gas Used For Solar



Description:



Silane is a colourless, flammable gas with a sharp, repulsive smell. Silane can be produced by several routes. Typically, it arises from the reaction of hydrogen chloride with magnesium silicide:It is also prepared from metallurgical grade silicon in a two-step process. First, silicon is treated with hydrogen chloride at about 300 °C to produce trichlorosilane, HSiCl3, along with hydrogen gas, according to the chemical equation.



The trichlorosilane is then converted to a mixture silane and silicon tetrachloride. This redistribution reaction requires a catalyst.



Specifications:



1. Physical properties



Item Specifications
Purity ≥99.9%
Silicon tetrachloride ≤300ppm
Chlorine ≤10ppm
Conclusion The results conforms with Enterprise standards





2. Typical technical data



Item Purity
Silane (SiH4) 99.99% 99.999% 99.9999%

Oxygen+Argon

(O2+Ar)

≤1 ppmv ≤0.4 ppmv ≤0.1 ppmv
Nitrogen (N2) ≤1 ppmv ≤0.2 ppmv ≤0.1 ppmv
Helium (He) / ≤10 ppmv ≤10 ppmv
Moisture (H2O) ≤1 ppmv ≤0.2 ppmv ≤0.1 ppmv
Hydrogen (H2) ≤50 ppmv ≤30 ppmv ≤20 ppmv
Total Hydrocarbons (THC) ≤0.2 ppmv ≤0.2 ppmv ≤0.1 ppmv
CO2+CO ≤0.4 ppmv ≤0.2 ppmv ≤0.1 ppmv
Chlorosilanes ≤15 ppmv ≤0.2 ppmv ≤0.1 ppmv
Disiloxane ≤1 ppmv ≤0.2 ppmv ≤0.1 ppmv
Didilane ≤1 ppmv ≤0.2 ppmv ≤0.1 ppmv





3. Package



47Ltr Cylinder /440Ltr Y Cylinder
Filling Net Weight/Cyl: 10Kgs /125Kgs
QTY Loaded in 20'Container: 216 Cyls/ 8Cyls



4. Applications:

Several industrial and medical applications exist for silane and functionalized silanes.



1 silanes are used as coupling agents to adhere fibers such as glass fibers and carbon fibers to certain polymer matrices, stabilizing the composite material.
2 They can also be used to couple a bio-inert layer on a titanium implant.
3 Other applications include water repellents, masonry protection, control of graffiti, applying polycrystalline silicon layers on silicon wafers when manufacturing semiconductors, and sealants.
4 Silane is also used in supersonic combustion ramjets to initiate combustion in the compressed air stream. As it can burn using carbon dioxide as an oxidizer it is a candidate fuel for engines operating on Mars.
5 Silane and similar compounds containing Si—H bonds are used as reducing agents in organic and organometallic chemistry.
6 Silane methacrylates are used in dentistry as part of tooth-colored, composite filling material. Silane methacrylates act as a coupling agent between the hard, silicate-based, ceramic filler and the organic, resin-based oligomer matrix.
