Detail Information

Product Name:	Silane	Purity:	99.9999%
CAS No.:	7803-62-5	EINECS No.::	232-263-4
Appearance:	Colorless Gas	Odor:	Repulsive
Melting Point:	-185°C	Boiling Point:	-112°C
Highlight:	electric gas , purity plus specialty gases

Product Description

Ultra High Purity 99.9999% SiH4 Silane Gas Used For Solar

Description:

Silane is a colourless, flammable gas with a sharp, repulsive smell. Silane can be produced by several routes. Typically, it arises from the reaction of hydrogen chloride with magnesium silicide:It is also prepared from metallurgical grade silicon in a two-step process. First, silicon is treated with hydrogen chloride at about 300 °C to produce trichlorosilane, HSiCl3, along with hydrogen gas, according to the chemical equation.

The trichlorosilane is then converted to a mixture silane and silicon tetrachloride. This redistribution reaction requires a catalyst.

Specifications:

1. Physical properties

Item	Specifications
Purity	≥99.9%
Silicon tetrachloride	≤300ppm
Chlorine	≤10ppm
Conclusion	The results conforms with Enterprise standards

2. Typical technical data

Item	Purity
Silane (SiH4)	99.99%	99.999%	99.9999%
Oxygen+Argon (O2+Ar)	≤1 ppmv	≤0.4 ppmv	≤0.1 ppmv
Nitrogen (N2)	≤1 ppmv	≤0.2 ppmv	≤0.1 ppmv
Helium (He)	/	≤10 ppmv	≤10 ppmv
Moisture (H2O)	≤1 ppmv	≤0.2 ppmv	≤0.1 ppmv
Hydrogen (H2)	≤50 ppmv	≤30 ppmv	≤20 ppmv
Total Hydrocarbons (THC)	≤0.2 ppmv	≤0.2 ppmv	≤0.1 ppmv
CO2+CO	≤0.4 ppmv	≤0.2 ppmv	≤0.1 ppmv
Chlorosilanes	≤15 ppmv	≤0.2 ppmv	≤0.1 ppmv
Disiloxane	≤1 ppmv	≤0.2 ppmv	≤0.1 ppmv
Didilane	≤1 ppmv	≤0.2 ppmv	≤0.1 ppmv

3. Package

47Ltr Cylinder /440Ltr Y Cylinder
Filling Net Weight/Cyl: 10Kgs /125Kgs
QTY Loaded in 20'Container: 216 Cyls/ 8Cyls

4. Applications:

Several industrial and medical applications exist for silane and functionalized silanes.

1	silanes are used as coupling agents to adhere fibers such as glass fibers and carbon fibers to certain polymer matrices, stabilizing the composite material.
2	They can also be used to couple a bio-inert layer on a titanium implant.
3	Other applications include water repellents, masonry protection, control of graffiti, applying polycrystalline silicon layers on silicon wafers when manufacturing semiconductors, and sealants.
4	Silane is also used in supersonic combustion ramjets to initiate combustion in the compressed air stream. As it can burn using carbon dioxide as an oxidizer it is a candidate fuel for engines operating on Mars.
5	Silane and similar compounds containing Si—H bonds are used as reducing agents in organic and organometallic chemistry.
6	Silane methacrylates are used in dentistry as part of tooth-colored, composite filling material. Silane methacrylates act as a coupling agent between the hard, silicate-based, ceramic filler and the organic, resin-based oligomer matrix.

Ultra High Purity 99.9999% SiH4 Silane Electronic Gases / Electric Gas Colorless 0

Tag:

Place of Origin:	China
Brand Name:	Newradar Gas
Certification:	ISO/DOT/GB
Model Number:	N/A

Minimum Order Quantity:	1 pcs
Price:	negotiation
Packaging Details:	Packed in 40L-50L, 440L cylinder or packed according to the demands.
Delivery Time:	15-25 working days after received your payment
Payment Terms:	L/C, , T/T, Western Union, MoneyGram
Supply Ability:	2000 pcs per month
