Place of Origin: | China |
---|---|
Brand Name: | Newradar Gas |
Certification: | ISO/DOT/GB |
Model Number: | N/A |
Minimum Order Quantity: | 1000 kilogram |
Price: | negotiation |
Packaging Details: | 10kg, 40kg or 50kg packed in the qualified gas cylinder or packed according to the demands. |
Delivery Time: | 15-25 working days after received your payment |
Payment Terms: | L/C, , T/T, Western Union, MoneyGram |
Supply Ability: | 3,00 ton per month |
Generally Transported: | Liquefied Compressed Gas | Typical: | A Nonpolar Gas |
---|---|---|---|
CAS No.: | 2551-62-4 | MF:: | SF6 |
FilFilling Pressure: | 150-200 Bar | Other Names: | (OC-6-11)-Sulfurfluoride |
Application: | Circuit Breaker,high-voltage Transmission Line, CIS, Large Cable Coil, Mutual Inductor, Lightning Arrester. | Stability:: | Stable. Non-flammable. Explodes On Contact With Disilane. Reacts With Sodium. |
Color: | Colorless | Purity: | 99.99%, 99.995%, 99.999% |
Highlight: | electric gas,purity plus specialty gases |
Non-Toxic Sulfur Hexafluoride Sf6 Electronic Gases Non Flammable Cas 2551-62-4
Description:
SF6 gas insulation of the electrical equipment Main features:
(1) small footprint, installation, easy to operate. Fully enclosed SF6 combination of electrical equipment, its structure is very compact, small size, use, installation covers an area of small. According to statistics, a fully enclosed combination of electrical appliances of the substation covers an area of only 20% of the open substation. SF6 circuit breaker and transformer installation, operation is relatively simple, the total weight is much lighter than the oil-filled equipment, the operation of the noise is also smaller.
(2) excellent performance, reliable travel. SF6 insulation characteristics than air, breaking capacity, for the excellent arc medium. Under the same conditions, its demon ability is equivalent to 100 times the air; after the demon does not produce free carbon and the like carbon material, safe and reliable operation.
Specifications:
1. Physical properties
Commodity | Sulfur hexafluoride |
Molecular Formula | SF6 |
CAS No. | 2551-62-4 |
UN No. | 1080 |
Hazardous Class | 2.2 |
Standard Package Container | 40L/150bar cylinder |
Cylinder Dimension | Φ219x1500mm |
Filling Weight | 50kg |
2. Typical technical data (COA)
Grade Classification | GB/T12022-2006 | High Purity |
4.5N | ||
(SF6) % | ≥99.9 | ≥99.995 |
Air % | ≤0.04 | ≤0.003 |
(CF4) % | ≤0.04 | ≤0.003 |
Water ppm | ≤5 | ≤1 |
Acidity ppm | ≤0.2 | ≤0.1 |
Hydrolyze fluoride(As HF) ppm | ≤1 | ≤0.2 |
Mineral oil ppm | ≤4 | ≤1 |
Toxicity | Non-tox. | Non |
Applications:
Electrical Industries Circuit Breaker |
leak detection and as a gaseous dielectric for transformers, condensers
|
As an inert gas
|
For the casting of magnesium.as an etchant in the semiconductor
|
As an inert filling |
Insulated glazing windows.
|
Dielectric medium |
SF6 is used in the electrical industry as a gaseous dielectric medium for high-voltage circuit breakers, switchgear, and other electrical equipment, often replacing oil filled circuit breakers (OCBs) that can contain harmful PCBs.
|
Medical use
|
SF6 is used to provide a tamponade or plug of a retinal hole in retinal detachment repair operations in the form of a gas bubble.SF6 is used as a contrast agent for ultrasound imaging. Sulfur hexafluoride microbubbles are administered in solution through injection into a peripheral vein.
|
Tracer compound |
Sulfur hexafluoride was the tracer gas used in the first roadway air dispersion model calibration; this research program was sponsored by the U.S. Environmental Protection Agency and conducted in Sunnyvale, California on U.S. Highway 101.Sulfur hexafluoride is also routinely used as a tracer gas in laboratory fume hood containment testing.
|
